Built for cinematic VR.

Built for cinematic VR. 8x 3/4 Sensors, 11K VR Photo + Video, FlowState™ Stabilization, Farsight Live Monitoring, 10 Bit Color, HDR Photos,“No-Stitch” Editing in Adobe Premiere Pro and CrystalView 11K Playback. This is Insta360 TITAN —— the ultimate toolket for the master of VR shooting.

8× Micro Four Thirds Sensors

11K VR

Photo + Video

Farsight Live Monitoring

FlowState Stabilization

HDR

CrystalView

11K Playback

“No-Stitch” Editing

in Adobe Premiere Pro

10-Bit

Color

8× MICRO

FOUR THIRDS

SENSORS

Micro Four Thirds sensors are the largest available in any unibody VR camera. They maximize Titan's image quality, dynamic range, low-light performance and color depth, raising the bar for high-end VR capture.

11K VR

Unparalleled Clarity

Titan is the first unibody VR camera to shoot at 11K mono and 10K 3D. VR has never looked this real.

Turn it up to 11K

It takes a lot of pixels to capture every angle at once. Titan sets a new benchmark with 11K resolution and ample 3.3-micron pixels. That's seven times higher than 4K.

11 K

@30fps

7

Times

higher than 4K

Exceptional Low-Light

Day or Night

Superb low-light performance puts Titan in a class of its own. Capture crisp, vibrant, noise-free VR, from dusk till dawn.

10 Bit Color

Colossal Color Depth

Titan supports shooting in 10 Bit color, allowing for billions of color combinations and surgical accuracy.

FlowState

Unshakeable Stabilisation

With a 9-axis gyro and advanced FlowState Stabilization, dynamic shots come out perfectly stable. No gimbal needed.

Specs

Diameter:

Φ228mm



Material:

Aluminum alloy



Lenses:

8 x 200° F3.2 fisheye lenses



Photos:

Real-time / Post-processing Stitching

10560 x 5280 (11K 2D)

10560 x 10560 (11K 3D)



Video:

Post-processing Stitching

10560 x 5280 @30fps (11K 2D)

9600 x 9600 @30fps (10K 3D)

7680 x 7680 @50fps

7680 x 3840 @60fps

5248 x 2624 @120fps



10-Bit Video

7680 x 7680 @30fps (8K 3D)

7680 x 3840 @30fps (8K 2D)



Real-time Stitching

3840 x 3840 @30fps (4K 3D)

3840 x 1920 @30fps (4K 2D)



Photo Files:

JPEG / DNG



Video Files:

MP4



Video Coding:

H264 and H265 in-camera, Pro RES 422 HQ is available when post stitching.



Live-streaming Modes:

Built-in server / Custom server / HDMI output 3840 x 1920 @30 fps ( 4K 2D livestream ) can store 8K 3D video while livestreaming. 3840 x 3840 @30 fps ( 4K 3D livestream ) can store 8K 3D video while livestreaming. Note: Simultaneous live-streaming + recording is supported.



Live-streaming Protocol:

rtsp, rtmp, hls, rtmps

Storage Specification:

9 × Full-size SD Cards



ISO Range:

100~6400

Exposure Modes:

Auto, Manual, Lens-by-Lens Custom, Shutter Priority (photo only), ISO Priority (photo only), Set ISO Upper Limit (video only).



White Balance Modes:

Automatic, manual



Photo Modes:

Single shot / Burst (10 continuous shots) / Timelapse / AEB (Auto Exposure Bracket, optional 3, 5, 7, and 9 photos for in-camera HDR photos)

Note: Both RAW and JPG can be selected for simultaneous shooting for synthetic HDR photos and all other photo modes.



Video Modes:

Standard (i-Log is available) / Binning (i-Log is available)



Bitrate Per Lens:

Up to 180Mbps



Power:

19V 9A adapter



Battery Capacity:

10000mAh removable battery



Operating Temperature:

0 - 40℃



Storage Temperature:

-20 - 40℃



WiFi Specifications:

802.11 b/g/n, 2.4GHz. Signal range is about 20 meters in open space. Max preview framerate of 30 FPS, supported in roughly a 5-meter range.

Antennae:

GPS signal antenna + WiFi signal antenna



Ethernet Port:

Yes



Video Transmission:

Insta360 Farsight provides ground-to-ground range of up to 300 meters and ground-to-air range of up to 1000 meters, with 30 FPS preview.



Audio:

4 Mono Microphones



Audio Coding Format:

AAC



Spatial Audio:

Ambisonic



Gyroscope:

Ultra-precise 9-axis gyroscope



Stabilization:

FlowState Stabilization



Stitching:

Optical Flow / Template



Exposure Range:

12 Stops



Supported Operating Systems:

Windows / Mac / iOS / Android

Built for

cinematic VR.
